Product Descriptions

The SMP100LC is a series of low capacitance transient surge arrestors designed for the protection of high data rate communication equipment. The low capacitance of the devices avoids any distortion of the signal and is

compatible with digital transmission line cards (xDSL, ISDN...).

SMP100LC series tested and confirmed compatible with Cooper Bussmann Telecom Circuit Protector TCP 1.25A.

The SMP100LC-xxx with the fuse TCP1.25A or TCP2A is compliant with Telcordia GR1089 (lightning and AC power fault tests),ITU-T K20/K21 (lightning and AC power faulttests), TIA/EIA-IS-968 (formerly FCC Part 68

lightning tests), and UL60950 (AC power faulttests). The use of the TCP1.25A allows the SMP100LC-xxx to be safe for the 2nd level (B criteria) AC power fault tests.

Product Features

■ Bidirectional crowbar protection

■ Voltage range from 8 V to 400 V

■ Low capacitance from 20 pF to 45 pF @ 2 V

■ Low leakage current: IR = 2 µA max

■ Holding current: IH = 150 mA min.

■ Repetitive peak pulse current: IPP = 100 A (10/1000 µs)

Benefits

■ Trisils are not subject to ageing and provide a fail safe mode in short circuit for better protection.

■ Helps equipment meet main standards such as

UL60950, IEC 950 / CSA C22.2 and UL1459.

■ Epoxy meets UL94, V0.

■ Package is JEDEC registered (DO-214AA).

Complies with the following standards

■ GR-1089 Core

■ ITU-T-K20/K21

■ IEC 61000-4-5

■ IEC 61000-4-2 level 4

■ TIA/EIA IS-968

■ UL497B recognized, UL file E136224

Product Applications

Any sensitive equipment requiring protection against lightning strikes and AC power faults. These devices are dedicated to central office protection as they comply with the most stressful standards. Their low capacitances make them suitable for xDSL.

Product Technical Parameter

Product Show
