Products Features

•VDD = +1.8V ±0.1V, VDDQ = +1.8V ±0.1V

•JEDEC-standard 1.8V I/O (SSTL_18-compatible)

•Differential data strobe (DQS, DQS#) option

•4n-bit prefetch architecture

•Duplicate output strobe (RDQS) option for x8

•DLL to align DQ and DQS transitions with CK

•8 internal banks for concurrent operation

•Programmable CAS latency (CL)

•Posted CAS additive latency (AL)

•WRITE latency = READ latency - 1 tCK

•Selectable burst lengths (BL): 4 or 8

•Adjustable data-output drive strength

•64ms, 8192-cycle refresh

•On-die termination (ODT)

•Industrial temperature (IT) option

•RoHS-compliant

•Supports JEDEC clock jitter specification
