Product details
The TPS 534 thermopile sensor in TO 5 type housing employs a chip of 1.2 x 1.2 mm2 absorber size and a 30 kV thermistor
as temperature reference. The round window opening is equipped with a 5.5 µm longpass (standard) infrared filter.
The sensor shows a flat sensitivity characteristics over the wavelength.
► Large absorber size - high signal output
► Low temperature coefficient of sensitivity
► Thermistor temperature reference included
► Applications in pyrometers, and - with additional infrared bandpass filters - in gas detectors
Product Description
Type | Description |
|---|---|
| ANSC PART# | ANSC - TPS56428RHLT |
Category | Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - DC DC Switching Regulators |
Mfr | Texas Instruments |
Series | D-CAP2™, Eco-Mode™ |
Packaging | Tape & Reel (TR) Cut Tape (CT) |
Part Status | Active |
Function | Step-Down |
Output Configuration | Positive |
Topology | Buck |
Output Type | Adjustable |
Number of Outputs | 1 |
Voltage - Input (Min) | 4.5V |
Voltage - Input (Max) | 18V |
Voltage - Output (Min/Fixed) | 0.6V |
Voltage - Output (Max) | 7V |
Current - Output | 4A |
Frequency - Switching | 650kHz |
Synchronous Rectifier | Yes |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 14-VFQFN Exposed Pad |
Supplier Device Package | 14-VQFN (3.5x3.5) |
Base Product Number | TPS56428 |
