Product Parameter

Supply voltage: 8-35V

Logic voltage: 5-12V

Reference voltage: 5.5V

Output on resistance: 320-430M ohms per driver

Diode forward voltage: 1.2V per driver

Output current of the driver: ± 2A

ARDUINO compatibility: Yes

Size: 6.8X5.2CM

Product Introduction

The Arduino interface is fully compatible with extensions. Arduino communication can be modified through I2C and address. It can adopt two motors and directly drive the output with PwM. Up to four DC brush motors or two four wire stepper motors can be connected. Using TB6612FNG motor driver chip, 1.2A driving capability, peak 3.2A, peak L298N module. We now have TB6612 MOSFET drivers with peak currents of 1.2A and 3A for each channel. It also has a lower motor voltage drop, so it can obtain greater torque from the battery. We did not use latches and Arduino PwM pins, but instead had a comprehensive dedicated PwM driver on the chip. This chip handles all motors and speed control on I2C. Driving multiple motors only requires two pins (SDA and SCL). Can be designed for stacking.

Product Funtions

Product Size

Product Show

Payment&Transportation

Official Certificate&Certificate

Multiple product supply

Company office environment

Warehouse Real Shot

Standard packaging

We also provide ：
