Product Introduction
This power meter is suitable for use in 12V-72V electric vehicles and can also measure lithium batteries, polymer batteries, nickel hydrogen batteries. It can also be used for other electricity/voltage measurement purposes. Not suitable for: large trucks, cranes, and other high-power and high load vehicles!
Product Parameters
Voltage allowable error ± 1;
8 battery levels 10 25 40 50 60 75 90 fully charged
Working current 5-15 mA
Refresh speed is about 480MS per time
Display mode: Three digit 0.28 "LED digital tube
Display color red or blue
Lead length 20CM
Dimensions 48X29X22 MM, length X width X thickness
Installation hole 46X27 MM
Net weight 7.7G
Gross weight 13.8G
Working temperature -10 ° C~65 ° C
Product Functions
1. The dual display battery level and voltage are clear at a glance. Display more intuitively. Up 8 color bars display (2 red and 6 green) battery level. Downward voltmeter (displaying battery voltage), the decimal point of the voltmeter automatically shifts with higher accuracy.
2. Wide range of applications, including lithium battery packs, lead-acid batteries, car batteries, electric vehicle batteries, and other types of battery electric devices. The principle of voltage calculation and electric vehicle power display meter is the same.
3. The meter head automatically recognizes voltage and electricity levels, and has reverse connection protection function (reverse connection will not burn)
Product Size
Product Show
Payment&Transportation
Official Certificate&Certificate
Multiple product supply
Company office environment
Warehouse Real Shot
Standard packaging
