Product Descriptions

MAX4466 is a low-power operational amplifier that has been optimized and can be used as a microphone preamplifier. They provide an ideal combination of optimized gain bandwidth products and power supply currents, as well as low voltage operation in ultra small packages. MAX4466 has gain stability and can provide a gain bandwidth of 200kHz with only a power supply current of 24 μ A. After decompression, it can achieve a minimum stable gain of+5V/V and provide a gain bandwidth product of 600kHz. In addition, these amplifiers also have rail to rail output, high AVOL, and excellent power supply rejection and common mode rejection ratios, making them suitable for working in noisy environments. Widely used in cellular phones, digital repeating devices, headphones, hearing aid microphone preamplifiers, portable computers, and speech recognition systems.

Product Features

Power supply voltage:+ 2.4V to+5.5V (can be directly connected to development boards such as STM/Arduino/Raspberry Pi)

Power suppression ratio: 112dB

Common mode rejection ratio: 126dB

AVOL: 125dB (RL=100k2) rail to rail output

Static power supply current:< 24μA

Gain bandwidth: 600kHz

Product Applications

Cellular phone

Digital repeating device

headset

hearing-aid

Microphone preamplifier

Portable computer

speech recognition system
