Product Overview
The LTM®8046 is an isolated flyback DC/DC µModule® (micromodule) converter. The LTM8046 has an isolation rating of 2kVAC. Included in the package are the switching controller, power switches, transformer, and all support components. Operatingoveraninputvoltagerangeof3.1V to 31V, the LTM8046 supports an output voltage range of 1.8V to 12V, set by one resistor. Only output, input, and bias capacitors are needed to finish the design. An optional capacitor can be used to set the soft-start period.
Product Features
2kVAC Isolated µModule Converter (Tested to 3kVDC)
UL 60950 Recognized ® , File E464570
Wide Input Voltage Range: 3.1V to 31V
5V at 550mA from 24VIN
1.8V to 12V Output Voltage
Current Mode Control
Programmable Soft-Start
User Configurable Undervoltage Lockout
SnPb or RoHS Compliant Finish
9mm × 15mm × 4.92mm BGA Package
Product Applications
Industrial Sensors
Industrial Switches
Ground Loop Mitigation
Product Description
Type | Description |
|---|---|
ANSC PART# | ANSC - LTM8056EY#PBF |
Category | Power Supplies - Board Mount DC DC Converters |
Mfr | - |
Series | µModule® |
Packaging | Tray |
Part Status | Active |
Type | Non-Isolated PoL Module |
Number of Outputs | 1 |
Voltage - Input (Min) | 5V |
Voltage - Input (Max) | 58V |
Voltage - Output 1 | 1.2 ~ 48V |
Voltage - Output 2 | - |
Voltage - Output 3 | - |
Current - Output (Max) | 5.4A |
Applications | ITE (Commercial) |
Features | OTP |
Operating Temperature | -40°C ~ 125°C |
Efficiency | 96% |
Mounting Type | Surface Mount |
Package / Case | 121-BBGA Module |
Size / Dimension | 0.59" L x 0.59" W x 0.19" H (15.0mm x 15.0mm x 4.9mm) |
Supplier Device Package | 121-BGA (15x15) |
Base Product Number | LTM8056 |
