Product Description
| Type# | Description |
| ANSC PART# | ANSC - XC2S50E-6TQG144C |
| Ihs Manufacturer | / |
| Part Package Code | QFP |
| Package Description | LEAD FREE, PLASTIC, TQFP-144 |
| Pin Count | 144 |
| Additional Feature | MAXIMUM USABLE GATES = 50000 |
| Clock Frequency-Max | 357 MHz |
| Combinatorial Delay of a CLB-Max | 0.47 ns |
| Length | 20 mm |
| Moisture Sensitivity Level | 3 |
| Number of CLBs | 384 |
| Number of Equivalent Gates | 23000 |
| Number of Inputs | 182 |
| Number of Logic Cells | 1728 |
| Number of Outputs | 182 |
| Number of Terminals | 144 |
| Operating Temperature-Max | 85 °C |
| Operating Temperature-Min | |
| Organization | 384 CLBS, 23000 GATES |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | LFQFP |
| Package Equivalence Code | QFP144,.87SQ,20 |
| Package Shape | SQUARE |
| Package Style | FLATPACK, LOW PROFILE, FINE PITCH |
| Peak Reflow Temperature (Cel) | 260 |
| Programmable Logic Type | FIELD PROGRAMMABLE GATE ARRAY |
| Qualification Status | Not Qualified |
| Seated Height-Max | 1.6 mm |
| Supply Voltage-Max | 1.89 V |
| Supply Voltage-Min | 1.71 V |
| Supply Voltage-Nom | 1.8 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | OTHER |
| Terminal Finish | Matte Tin (Sn) |
| Terminal Form | GULL WING |
| Terminal Pitch | 0.5 mm |
| Terminal Position | QUAD |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width | 20 mm |
Product Photos
