Product Introduction

As PCI evolves in today's complex systems, PLX continues to provide market leading high performance 32-bit PCI solutions. In this tradition, PLX offers the PCI 9052 I/O Accelerator. The PCI 9052 brings PLX's industry leading experience in the world of PCI designs to you in a way that is simple and convenient to use. The PCI 9052 is the ideal choice for implementation of your 32-bit, 33MHz PCI bus target (slave) I/O Accelerator designs for you 32-bit 40MHz, Industry Standard Architecture (ISA) local bus, or generic designs.

Add Target Functionality with Ease

The PCI 9052 has the industry's most flexible local bus, which allows for multiple interface options to a wide variety of memory and I/O devices. Combine that with fully tested, PCI r2.1 compliance, and your design risk is virtually zero. The PCI 9052 has a set of advanced features to provide high performance and flexibility in order to simplify your design, such as four programmable GPIOs, local chip select, prefetch read ahead mode, zero wait state bursting, and on-the-fly big/little endian byte conversion.

Products Connectivity

■ 32-bit, 33MHz PCI r2.1 compliant

■ Up to 40MHz local bus operation

■ ISA and Generic 32-bit, 40MHz local bus designs

■ Glueless ISA interface for low cost adapters

■ Supports multiplexed and nonmultiplexed 8-, 16-, and 32-bit generic local buses

■ 5V CMOS in 160-pin PQFP package

Products Performance

■ Zero wait state burst operation – PCI unlimited bursts transfers at up to 132MB/s

■ Direct slave data transfers –Access 8-, 16-, and 32-bit local bus devices

■ Deferred reads, read ahead, posted writes, programmable read prefetch counter

■ Move from 8MHz, 5MB/s ISA designs to leading 33MHz, 132MB/s PCI

■ Low power consumption
