Product Descriptions
The M74HC273 is an high speed CMOS OCTAL D TYPE FLIP FLOP WITH CLEAR fabricated with silicon gate C2MOS technology.
Information signals applied to D inputs are transferred to the Q outputs on the positive-going edge of the clock pulse.
When the CLEAR input is held low, the Q output are in the low logic level independent of the other inputs.
All inputs are equipped with protection circuits against static discharge and transient excess voltage.
Product Features
■ HIGH SPEED : fMAX = 66 MHz (TYP.) at VCC = 6V
■ LOW POWER DISSIPATION: ICC =4µA(MAX.) at TA=25°C
■ HIGH NOISE IMMUNITY: VNIH = VNIL = 28 % VCC (MIN.)
■ SYMMETRICAL OUTPUT IMPEDANCE: |IOH| = IOL = 4mA (MIN)
■ BALANCED PROPAGATION DELAYS: tPLH ≅ tPHL
■ WIDE OPERATING VOLTAGE RANGE: VCC (OPR) = 2V to 6V
■ PIN AND FUNCTION COMPATIBLE WITH 74 SERIES 273
Specifications
| Part# | M74HC273RM13TR |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Flip Flops | |
| Mfr | - |
| Series | 74HC |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Obsolete |
| Function | Master Reset |
| Type | D-Type |
| Output Type | Non-Inverted |
| Number of Elements | 1 |
| Number of Bits per Element | 8 |
| Clock Frequency | 66 MHz |
| Max Propagation Delay @ V, Max CL | 25ns @ 6V, 50pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Iq) | 4 µA |
| Input Capacitance | 5 pF |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 20-SO |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Base Product Number | 74HC273 |
