Hot sale original electronics MC33272ADG IC Single Supply, High Slew Rate, Low Input Offset Voltage Operational Amplifiers_Integrated Circuit

Product Details

Features

• Input Offset Voltage Trimmed to 100 V (Typ)

• Low Input Bias Current: 300 nA

• Low Input Offset Current: 3.0 nA

• High Input Resistance: 16 M

• Low Noise: 18 nV/ √ Hz @ 1.0 kHz

• High Gain Bandwidth Product: 24 MHz @ 100 kHz

• High Slew Rate: 10 V/s

• Power Bandwidth: 160 kHz

• Excellent Frequency Stability

• Unity Gain Stable: w/Capacitance Loads to 500 pF

• Large Output Voltage Swing: +14.1 V/ −14.6 V

• Low Total Harmonic Distortion: 0.003%

• Power Supply Drain Current: 2.15 mA per Amplifier

• Single or Split Supply Operation: +3.0 V to +36 V or

±1.5 V to ±18 V

• ESD Diodes Provide Added Protection to the Inputs

• NCV Prefix for Automotive and Other Applications Requiring

Unique Site and Control Change Requirements; AEC−Q100

Qualified and PPAP Capable

• Pb−Free Packages are Available

Product Description

TYPE	DESCRIPTION
ANSC PART#	ANSC-MC33272ADG
Category	Integrated Circuits (ICs)
	Linear
	Amplifiers
	Instrumentation, OP Amps, Buffer Amps
Mfr	/
Series	-
Packaging	Tube
Part Status	Obsolete
Amplifier Type	General Purpose
Number of Circuits	2
Output Type	-
Slew Rate	10V/µs
Gain Bandwidth Product	24 MHz
Current - Input Bias	300 nA
Voltage - Input Offset	100 µV
Current - Supply	2.15mA (x2 Channels)
Current - Output / Channel	37 mA
Voltage - Supply Span (Min)	3 V
Voltage - Supply Span (Max)	36 V
Operating Temperature	-40°C ~ 85°C
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOIC
Base Product Number	MC33272

MC33272ADG

For more information, please download

MC33272ADG

MC33272ADG 1

MC33272ADG 2
