EP2S130F1020C3 Stratix® II Field Programmable Gate Array IC 1020-BBGA

EP2S130F1020C3

Model:EP2S130F1020C3

Manufacturer:ALTERA

Package:1020-BBGA

Detail

Product Introduction



The Stratix® II FPGA family is based on a 1.2-V, 90-nm, all-layer copper  SRAM process and features a new logic structure that maximizes  performance, and enables device densities approaching 180,000  equivalent logic elements (LEs). Stratix II devices offer up to 9 Mbits of  on-chip, TriMatrix™ memory for demanding, memory intensive  applications and has up to 96 DSP blocks with up to 384 (18-bit × 18-bit)  multipliers for efficient implementation of high performance filters and  other DSP functions. Various high-speed external memory interfaces are  supported, including double data rate (DDR) SDRAM and DDR2  SDRAM, RLDRAM II, quad data rate (QDR) II SRAM, and single data  rate (SDR) SDRAM. Stratix II devices support various I/O standards  along with support for 1-gigabit per second (Gbps) source synchronous  signaling with DPA circuitry. Stratix II devices offer a complete clock  management solution with internal clock frequency of up to 550 MHz  and up to 12 phase-locked loops (PLLs). Stratix II devices are also the  industry’s first FPGAs with the ability to decrypt a configuration  bitstream using the Advanced Encryption Standard (AES) algorithm to  protect designs.


Product Features


■ New and innovative adaptive logic module (ALM), the basic  building block of the Stratix II architecture, maximizes performance  and resource usage efficiency

■ Up to 9,383,040 RAM bits (1,172,880 bytes) available without  reducing logic resources

■ TriMatrixmemory consisting of three RAM block sizes to implement  true dual-port memory and first-in first-out (FIFO) buffers

■ High-speed DSP blocks provide dedicated implementation of  multipliers (at up to 450 MHz), multiply-accumulate functions, and  finite impulse response (FIR) filters

■ Up to 16 global clocks with 24 clocking resources per device region

■ Clock control blocks support dynamic clock network enable/disable,  which allows clock networks to power down to reduce power  consumption in user mode

■ Up to 12 PLLs (four enhanced PLLs and eight fast PLLs) per device  provide spread spectrum, programmable bandwidth, clock switchover, real-time PLL reconfiguration, and advanced multiplication  and phase shifting

■ Support for numerous single-ended and differential I/O standards

■ High-speed differential I/O support with DPA circuitry for 1-Gbps  performance

■ Support for high-speed networking and communications bus  standards including Parallel RapidIO, SPI-4 Phase 2 (POS-PHY  Level 4), HyperTransport™ technology, and SFI-4

■ Support for high-speed external memory, including DDR and DDR2  SDRAM, RLDRAM II, QDR II SRAM, and SDR SDRAM

■ Support for multiple intellectual property megafunctions from  Altera MegaCore® functions and Altera Megafunction Partners  Program (AMPPSM) megafunctions

■ Support for design security using configuration bitstream  encryption

■ Support for remote configuration updates


Product Specifications


AttributeAttribute value
ANSM-Part#ANSM-EP2S130F1020C3
CategoryIntegrated Circuits (ICs)
Embedded
FPGAs (Field Programmable Gate Array)
MfrAltera
SeriesStratix® II
PackagingBulk
Part StatusActive
DigiKey ProgrammableNot Verified
Number of I/O742
Voltage - Supply1.15V ~ 1.25V
Mounting TypeSurface Mount
Operating Temperature0°C ~ 85°C (TJ)
Package / Case1020-BBGA
Supplier Device Package1020-FBGA (33x33)
Base Product NumberEP2S130
