Product Description
The AD780ARZ-REEL7 is a three-terminal voltage reference IC from Analog Devices Inc. This surface-mountable IC is designed to provide a high accuracy and low noise voltage reference for various applications. The AD780ARZ-REEL7 is a user-configurable IC that can be set to either 2.5V or 3.0V reference voltage, making it a versatile component for a wide range of applications.
Product Features
· High accuracy and low noise voltage reference
· User-configurable output voltage (2.5V or 3.0V)
· Low quiescent current (1mA)
· Operating temperature range of -40°C to 85°C
· RoHS3 compliant and contains lead
· 8-pin SOIC package with a tape and reel packaging option
Product Applications
· Primary applications: Precision voltage references for industrial control systems, medical devices, and automotive systems
· Secondary applications: Audio and video equipment, telecommunications, and consumer electronics
Product Description
| Type | Description |
| ANSC PART# | ANSC - AD780ARZ-REEL7 |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Reference | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Part Status | Active |
| Reference Type | Series, Shunt |
| Output Type | Programmable |
| Voltage - Output (Min/Fixed) | ±2.5V, ±3V |
| Current - Output | 10 mA |
| Tolerance | ±0.2%, ±0.17% |
| Temperature Coefficient | 7ppm/°C |
| Noise - 0.1Hz to 10Hz | 4µVp-p |
| Noise - 10Hz to 10kHz | - |
| Voltage - Input | 4V ~ 36V |
| Current - Supply | 1mA |
| Current - Cathode | 1 mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | AD780 |
