Product Overview
In a Tube case, the IC voltage regulator is delivered. A 12-WFDFN Exposed Pad case contains the Liner IC. This PMIC chip has an output type of Adjustable. In this electrical part, there are 1 regulators that are implemented. Voltage Regulated IC Surface Mount varies its operating temperature range. The IC Voltage Regulator's operating temperature is -40°C~150°C TJ degrees. Currently, this regulator IC has an output function configured as Negative as its output function. The current output of this IC regulator is 500mA.
Product Features
Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) Protection Features
Negative Output Configuration
Adjustable Output Type
Product Applications
LT3094HDD#PBF Linear Voltage Regulators applications.
· Portable telephone
· Electronic notebook
· Camera
· Video equipment
· CPU power supply
· Switching regulator
· Multiple-power supply system
· Digital audio player
· Digital TV
· Smartcard
Product Description
|
Type |
Description |
|---|---|
|
ANSC PART# |
ANSC - LT3094HDD#PBF |
|
Category |
Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators |
|
Mfr |
/ |
|
Series |
- |
|
Packaging |
Tube |
|
Part Status |
Active |
|
Output Configuration |
Negative |
|
Output Type |
Adjustable |
|
Number of Regulators |
1 |
|
Voltage - Input (Max) |
-2.3V |
|
Voltage - Output (Min/Fixed) |
-19.5V |
|
Voltage - Output (Max) |
0V |
|
Voltage Dropout (Max) |
0.41V @ 500mA |
|
Current - Output |
500mA |
|
Current - Quiescent (Iq) |
2.35 mA |
|
Current - Supply (Max) |
23 mA |
|
PSRR |
108dB ~ 28dB (120Hz ~ 10MHz) |
|
Control Features |
Enable, Power Good, Soft Start |
|
Protection Features |
Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) |
|
Operating Temperature |
-40°C ~ 150°C (TJ) |
|
Mounting Type |
Surface Mount |
|
Package / Case |
12-WFDFN Exposed Pad |
|
Supplier Device Package |
12-DFN (3x3) |
|
Base Product Number |
LT3094 |
