Product Overview
This harley voltage regulator utilizes the Tape & Reel (TR) package for optimized performance. There are 8 terminations in this voltage regulator. The type of analog IC that this voltage regulator is equipped with is SWITCHING REGULATOR. This harley voltage regulator is available in the 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad package for the purpose of space saving. DC DC switching regulator is configured with 1 outputs. This DC DC switching regulator generates Adjustable output on its output pins. This voltage regulator 12v fits the Surface Mount mounting. When operating, adjusting voltage regulator's operating temperature should be kept at -40°C~125°C TJ. The switching frequency of this DC-DC switching regulator reaches 200kHz~2MHz. This voltage regulator is able to operate with the minimal input voltage of 2.5V. DC DC switching regulator's output voltage (Min/Fixed) amounts to 5V. The output current of 2A Switch makes dc to dc voltage regulator feature maximum design flexibility. Voltage regulator has an input voltage (Max) of 32V. The peak reflow temperature of this regulator amounts to 260 to be essentially indestructible. Voltage regulator is designed to provide a nominal input voltage of 5V to meet the operation requirements. This DC/DC regulator belongs to the LT3580 family. The adjusting voltage regulator's output voltage is maintain at 12V. 8 pins are used for switching regulator operation. DC DC switching regulator is able to operate in an easy way on the basis of the maximal output voltage of 42V Switch.
Product Features
1 outputs
Peak reflow temperature (Cel) of 260
8 pins
Product Applications
LT3580IMS8E#TRPBF Voltage Regulators applications.
· CNC system
· Servo drive system
· Digital display device
· Linear guide
· Ball screw pair
· Computer application technology
· Network technology
· Automation technology
· CMM
Product Description
|
Type |
Description |
|---|---|
|
ANSC PART# |
ANSC - LT3580IMS8E#TRPBF |
|
Category |
Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - DC DC Switching Regulators |
|
Mfr |
/ |
|
Series |
- |
|
Packaging |
Tape & Reel (TR) Cut Tape (CT) |
|
Part Status |
Active |
|
Function |
Step-Up, Step-Up/Step-Down |
|
Output Configuration |
Positive or Negative |
|
Topology |
Boost, Cuk, SEPIC |
|
Output Type |
Adjustable |
|
Number of Outputs |
1 |
|
Voltage - Input (Min) |
2.5V |
|
Voltage - Input (Max) |
32V |
|
Voltage - Output (Min/Fixed) |
5V |
|
Voltage - Output (Max) |
42V (Switch) |
|
Current - Output |
2A (Switch) |
|
Frequency - Switching |
200kHz ~ 2MHz |
|
Synchronous Rectifier |
No |
|
Operating Temperature |
-40°C ~ 125°C (TJ) |
|
Mounting Type |
Surface Mount |
|
Package / Case |
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad |
|
Supplier Device Package |
8-MSOP-EP |
|
Base Product Number |
LT3580 |
