Product Details
| TPS7A4700RGWT Description Single Schottky rectifier suited for Switch Mode Power Supply and high frequency DC to DC converters. Packaged either in TO-220AC, ISOWATT220AC, TO-220FPAC or D2PAK, this device is intended for use in low voltage, high frequency inverters, free wheeling and polarity protection applications. TPS7A4700RGWT Features ■ Very small conduction losses ■ Negligible switching losses ■ Extremely fast switching ■ Insulated package: ISOWATT220AC, TO-220FPAC Insulating voltage = 2000V DC Capacitance = 12pF |
Product Description
Type | Description |
|---|---|
| ANSC PART# | ANSC- TPS7A4700RGWT |
Category | Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators |
Mfr | / |
Series | - |
Packaging | Tape & Reel (TR) Cut Tape (CT) |
Part Status | Active |
Output Configuration | Positive |
Output Type | Adjustable |
Number of Regulators | 1 |
Voltage - Input (Max) | 35V |
Voltage - Output (Min/Fixed) | 1.4V |
Voltage - Output (Max) | 20.5V |
Voltage Dropout (Max) | 0.45V @ 1A |
Current - Output | 1A |
Current - Quiescent (Iq) | 1 mA |
Current - Supply (Max) | 6.1 mA |
PSRR | 78dB (1kHz) |
Control Features | Enable |
Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
Operating Temperature | -40°C ~ 125°C |
Mounting Type | Surface Mount |
Package / Case | 20-VQFN Exposed Pad |
Supplier Device Package | 20-VQFN (5x5) |
Base Product Number | TPS7A4700 |
