Product Overview
There is a 28-VFQFN Exposed Pad package on the board that RF transceiver IC is used to save space. RF transceiver's mounting is done according to the Surface Mount method.With transceiver RF's high efficiency and reliable performance, it emerges as a TxRx + MCU.A high level of reliability is provided by using an advanced transceiver RF' packaging Tape & Reel (TR).28 pins are provided on the transceiver RF circuit board.Try searching for CC2520 variants of the transceiver.The mount is provided by Surface Mount.In the 2.4GHz frequency range, RF transceiver operates .
Product Features
28-VFQFN Exposed Pad package
Surface Mount for mounting
TxRx + MCU
Tape & Reel (TR) is used
28 pins
Use CC2520
Product Applications
CC2520RHDT RF Transceiver ICs applications
Security Systems
M2M Communication
Remote Device Management
Low-power IoT applications
LoT applications
Power Amplifier (PA)
Low Noise Amplifier (LNA)
Transmit
Receive
Switch
Product Description
| Type | Description |
| ANSC PART# | ANSC- CC2520RHDT |
| Category | RF and Wireless |
| RF Transceiver ICs | |
| Mfr | - |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Part Status | Active |
| DigiKey Programmable | Not Verified |
| Type | TxRx + MCU |
| RF Family/Standard | 802.15.4 |
| Protocol | Zigbee® |
| Modulation | DSSS, O-QPSK |
| Frequency | 2.4GHz |
| Data Rate (Max) | 250kbps |
| Power - Output | 5dBm |
| Sensitivity | -98dBm |
| Memory Size | 768B RAM |
| Serial Interfaces | SPI |
| GPIO | 6 |
| Voltage - Supply | 1.8V ~ 3.8V |
| Current - Receiving | 18.5mA ~ 22.3mA |
| Current - Transmitting | 25.8mA ~ 33.6mA |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 28-VFQFN Exposed Pad |
| Supplier Device Package | 28-VQFN (5x5) |
| Base Product Number | CC2520 |
