Product Descriptions

The HEF4024B is a 7-stage binary ripple counter with a clock input (CP), and overriding asynchronous master reset input (MR) and seven fully buffered parallel outputs (O0 to O6). The counter advances on the HIGH to LOW transition of CP. A HIGH on MR clears all counter stages and forces all outputs LOW, independent of CP. Each counter stage is a static toggle flip-flop.

Product Photos

For more product information, please download the PDF
