Product Details
MCP9700T-E/LT Overview
For safety reasons, these analog sensors are packaged in the Tape & Reel (TR).
To prevent damage to the analog sensors, they are packaged in 5-TSSOP, SC-70-5, SOT-353 packages. For proper operation, this sensor has 5 pins.
This electronic part has 6 terminations. Analog sensors could supply 6μA current when operating.
DC circuit should have a maximum voltage of 5.5V.
The minimum voltage supplied by this magnetic switch can be 2.3V in a DC circuit, however. When operating,
the analog sensors could supply 5.5V voltage.
In theory, this sensor can be powered by 6μA current. There are 5 pins on it.
For optimal performance, the sensor's current output should be 100μA.
In general, the sensor should output 500mV.
MCP9700T-E/LT Features
Moisture Sensitivity Level (MSL): 1 (Unlimited)
Tape & Reel (TR) Package
Operating Temperature: -40°C~125°C
Supply Voltage: 2.3V~5.5V
5 Pins
Local Sensing Temperature: -40°C~125°C
6 Terminations
Highest (Lowest) Accuracy: ±2°C (-4°C, +6°C)
Sensor Type: Analog, Local
MCP9700T-E/LT Applications
There are a lot of Microchip Technology
MCP9700T-E/LT Analog & Digital Sensors applications.
Energy saving at office (air-conditining/ighting control)
Digital signage
Automatic doors/elevators
Industrial
HVAC
Disk Drives
Automotive
Portable Medical Instruments
Computers
Battery Management
Product Description
| ANSC PART # | ANSC- MCP9700T-E/LT |
| PART# | MCP9700T-E/LT |
| TYPE | Electronic components &Bom x |
TYPE | DESCRIPTION |
|---|---|
Category | Sensors, Transducers Temperature Sensors Analog and Digital Output |
Mfr | Microchip Technology |
Series | - |
Package | Tape & Reel (TR) Cut Tape (CT) |
Product Status | Active |
Sensor Type | Analog, Local |
Sensing Temperature - Local | -40°C ~ 125°C |
Sensing Temperature - Remote | - |
Output Type | Analog Voltage |
Voltage - Supply | 2.3V ~ 5.5V |
Resolution | 10mV/°C |
Features | - |
Accuracy - Highest (Lowest) | ±2°C (-4°C, +6°C) |
Test Condition | 0°C ~ 70°C (-40°C ~ 125°C) |
Operating Temperature | -40°C ~ 125°C |
Mounting Type | Surface Mount |
Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
Supplier Device Package | SC-70-5 |
Base Product Number | MCP9700 |
