Product Overview
This device has a DC current gain of 1000 @ 20A 5V, which is the ratio between the collector current and the base current.A collector emitter saturation voltage of 3V allows maximum design flexibility.A VCE saturation indicates a maximum value of Ic (saturation), and a maximum value of VCE saturation (Max).A constant collector voltage of 30A is necessary for high efficiency.The base voltage of the emitter can be kept at 5V to achieve high efficiency.Normally, a fuse's current rating refers to how much current it can carry without deteriorating too much, which in this case is 30A.In this part, there is a transition frequency of 4MHz.The maximum collector current is 30A volts.
Product Features
the DC current gain for this device is 1000 @ 20A 5V
a collector emitter saturation voltage of 3V
the vce saturation(Max) is 4V @ 300mA, 30A
the emitter base voltage is kept at 5V
the current rating of this device is 30A
a transition frequency of 4MHz
Product Applications
Inverter
Interface
Driver
Muting
Product Description
Type | Description |
|---|---|
ANSC PART# | ANSC - MJ11016G |
Category | Discrete Semiconductor Products Transistors Bipolar (BJT) Single Bipolar Transistors |
Mfr | / |
Series | - |
Packaging | Tray |
Part Status | Active |
Transistor Type | NPN - Darlington |
Current - Collector (Ic) (Max) | 30 A |
Voltage - Collector Emitter Breakdown (Max) | 120 V |
Vce Saturation (Max) @ Ib, Ic | 4V @ 300mA, 30A |
Current - Collector Cutoff (Max) | 1mA |
DC Current Gain (hFE) (Min) @ Ic, Vce | 1000 @ 20A, 5V |
Power - Max | 200 W |
Frequency - Transition | 4MHz |
Operating Temperature | -55°C ~ 200°C (TJ) |
Mounting Type | Through Hole |
Package / Case | TO-204AA, TO-3 |
Supplier Device Package | TO-204 (TO-3) |
Base Product Number | MJ11016 |
