Product Details
Product Description:
The BNX022-01 is a high-performance, surface-mountable data line filter from Murata Electronics, designed to provide reliable
and efficient signal filtering in various electronic applications.
This integrated circuit (IC) is part of Murata's extensive range of filtering solutions, offering a compact and robust design
that meets the demands of modern electronics.
Features:
Filter Type: DATA LINE FILTER
Operating Temperature Range: -40°C to 125°C
Rated Voltage: 50V
Rated Current: 10A
Output Impedance: 50Ω
Insulation Resistance: ≥ 500 MΩ
Insertion Loss: ≤ 35 dB
Mounting Type: SURFACE MOUNT
Physical Dimensions: L12.1XB9.1XH3.1 mm (L0.476XB0.358XH0.122 inch)
Applications:
Primary applications: Data transmission and reception in industrial automation, medical equipment, and automotive systems.
Secondary applications: Signal filtering in consumer electronics, telecommunications, and aerospace systems.
Product Description
| Type# | Description |
| ANSC PART# | ANSC -BNX022-01 |
| Manufacturer | MURATA |
| Filter Type | DATA LINE FILTER |
| Height | 3.1 mm |
| Insertion Loss-Max | 35 dB |
| Insulation Resistance-Min | 500 MΩ |
| Length | 12.1 mm |
| Mounting Type | SURFACE MOUNT |
| Number of Functions | 3 |
| Operating Temperature-Max | 125 °C |
| Operating Temperature-Min | -40 °C |
| Output Impedance | 50 OHM Ω |
| Rated Current | 10 A |
| Rated Voltage | 50 V |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) |
| Width | 9.1 mm |
