Description The TPD2EUSB30, TPD2EUSB30A, and TPD4EUSB30 are 2 and 4 channel Electrostatic Discharge (ESD) protection diode arrays based on Transient Voltage Suppressor (TVS). The TPDxEUSB30/A devices are rated to dissipate ESD strikes at the maximum level specified in the international standard IEC 61000-4-2. (Contact). These devices also have peak pulse current ratings of 5 A (8/20 s) per IEC 61000-4-5 (Surge) specification. Features • Supports USB 3.0 data rates (5 Gbps) • IEC 61000-4-2 ESD protection (level 4 contact) • IEC 61000-4-5 surge protection – 5 A (8/20 µs) • Low capacitance – DRT: 0.7 pF (typical) – DQA: 0.8 pF (typical) • Dynamic resistance: 0.6 Ω (typical) • Space-saving DRT, DQA packages • Flow-through pin mapping Applications • Media players • Portable computers • Notebooks • Set-top boxes • DVD players |
Product Description
| Type | Description |
| ANSC PART# | ANSC - TPD2EUSB30ADRTR |
| Category | Circuit Protection |
| Transient Voltage Suppressors (TVS) | |
| TVS Diodes | |
| Mfr | Original |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| / | |
| Part Status | Active |
| Type | Zener |
| Unidirectional Channels | 2 |
| Voltage - Reverse Standoff (Typ) | 3.6V (Max) |
| Voltage - Breakdown (Min) | 4.5V |
| Voltage - Clamping (Max) @ Ipp | 8V |
| Current - Peak Pulse (10/1000µs) | 1A (8/20µs) |
| Power - Peak Pulse | 45W |
| Power Line Protection | Yes |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 3-SMD, SOT-23-3 Variant |
| Supplier Device Package | SOT-3 |
| Base Product Number | TPD2EUSB30 |
