Product Details
| General description Low capacitance bi-directional double ESD protection diode in the small SOT23 plastic package designed to protect 2 data lines from the damage caused by Electro Static Discharge (ESD) and other transients. Features ■ Bi-directional ESD protection of 2 lines ■ Low diode capacitance ■ Max. peak pulse power: Ppp = 130 W at tp = 8/20 µs ■ Low clamping voltage: VCL(R) = 14 V at Ipp = 12 A ■ Ultra low leakage current: IRM = 5 nA at VRWM = 5 V ■ ESD protection > 30 kV ■ IEC 61000-4-2; level 4 (ESD) ■ IEC-61000-4-5 (surge); Ipp = 12 A at tp = 8/20 µs. Applications ■ Cellular handsets and accessories ■ Portable electronics ■ Computers and peripherals ■ Communication systems ■ Audio and video equipment. |
Product Description
| Type# | Description |
| ANSC PART# | ANSC- PESD5V0S1BA |
| Ihs Manufacturer | Original |
| Package Description | SC-76, 2 PIN |
| Additional Feature | LOW CAPACITANCE |
| Breakdown Voltage-Max | 9.5 V |
| Breakdown Voltage-Min | 5.5 V |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE |
| Moisture Sensitivity Level | 1 |
| Non-rep Peak Rev Power Dis-Max | 130 W |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 150 °C |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE |
| Peak Reflow Temperature (Cel) | 260 |
| Polarity | BIDIRECTIONAL |
| Reference Standard | IEC-60134; IEC-61000-4-2, 4-5 |
| Rep Pk Reverse Voltage-Max | 5 V |
| Surface Mount | YES |
| Technology | AVALANCHE |
| Terminal Finish | TIN |
| Terminal Form | GULL WING |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
