Product Details
| DESCRIPTION The 1N5767 and the 1N5957 PIN diodes are based upon low capacitance PIN chips designed with long minority carrier lifetime, and thick intrinsic width. Thus operation as low as 1 MHz is possible with low distortion. Additionally, the low diode capacitance allows useful operation well into the microwave frequency range. ■ Useful attenuation from 1 µA to 100 mA bias ■ Capacitance below 0.4 pF ■ Low distortion in switches and attenuators ■ Rugged Microsemi construction. APPLICATIONS/BENEFITS ■ Surface mount package available ■ RoHS compliant packaging available Popular Search Similar Parts Related Categories |
Product Description
| Type | Description |
| ANSC PART# | ANSC -1N5767 |
| Category | Discrete Semiconductor Products |
| Diodes | |
| RF Diodes | |
| Manufacturer | Original |
| Series | 1N5767 |
| Packaging | Tray |
| Part Status | Active |
| Diode Type | PIN - Single |
| Voltage - Peak Reverse (Max) | 100V |
| Capacitance @ Vr, F | 0.4pF @ 100V, 1MHz |
| Resistance @ If, F | 2.5Ohm @ 100mA, 100MHz |
| Power Dissipation (Max) | 400 mW |
| Operating Temperature | -65°C ~ 175°C |
| Grade | - |
| Qualification | - |
| Package / Case | Axial |
| Supplier Device Package | Axial |
