Product Features

Outer diameter: 48mm

Resolution: 1000 - 6000 C/T with U, V, W commutation signals

High frequency response: 200 kHz max.-20° C to +100° C operating temperature

Standard line driver outputs provide increased noise immunity and longer cable capability (up to 1 km)

Typical applications: AC servo motor feedback devices

Two types available: Standard, 14 wire and Reduced wiring, 8 wire

Application

·Brushless DC servo motor control

Features

·Easy to install
