Product Description
The ESDS312DBVR is a unidirectional TVS (Transient Voltage Suppressor) diode from Texas Instruments, designed for surface-mount applications. This device is part of the ESDS312 family and is suitable for general-purpose use. With a peak pulse current of 25A and a power rating of 170W, it provides reliable protection against voltage transients and surges.
Product Features
Unidirectional TVS diode with a voltage breakdown of 4.5V and a clamping voltage of 6.5V typ
Peak pulse current of 25A and power rating of 170W
Silicon diode element material
Available in a surface-mount package (SC-74A, SOT-753) with a matte tin (Sn) finish
RoHS3 compliant and Pb-free
Operating temperature range of -40°C to 125°C
Moisture sensitivity level of 1 (unlimited)
Product Applications
Primary applications: General-purpose voltage protection in electronic devices, such as consumer electronics, industrial equipment, and automotive systems
Secondary applications: Surge protection in telecommunications, medical devices, and aerospace systems
Product Description
Type | Description |
|---|---|
ANSC PART# | ANSC - ESDS312DBVR |
Category | Circuit Protection Transient Voltage Suppressors (TVS) TVS Diodes |
Mfr | Texas Instruments |
Series | - |
Packaging | Tape & Reel (TR) Cut Tape (CT) |
Part Status | Active |
Type | Zener |
Unidirectional Channels | 2 |
Voltage - Reverse Standoff (Typ) | 3.6V (Max) |
Voltage - Breakdown (Min) | 4.5V |
Voltage - Clamping (Max) @ Ipp | 6.5V (Typ) |
Current - Peak Pulse (10/1000µs) | 25A (8/20µs) |
Power - Peak Pulse | 170W |
Power Line Protection | No |
Applications | General Purpose |
Capacitance @ Frequency | 4.5pF @ 1MHz |
Operating Temperature | -40°C ~ 125°C (TA) |
Mounting Type | Surface Mount |
Package / Case | SC-74A, SOT-753 |
Supplier Device Package | SOT-23-5 |
Base Product Number | ESDS312 |
