Product Overview
An acceptable reverse voltage would be 200V.As a result, this device has a rectified current of 4A volts on average.Phase diode rectifier is permissible for forward current to reach 4A.Fuse elements have an indefinite life expectancy of 4A, which is the maximum current that the fuse can carry for an indefinite period of time.There is no maximum value for 125A surge current.Based on the data charts in the datasheets, the peak reverse is 5μA.
Product Features
an average rectified current of 4A volts
a current rating of 4A
the peak reverse is 5μA
Product Applications
MUR420 applications of single-phase diode rectifier.
· DC motor control and drives
· Battery chargers
· Welders
· Power converters
· Reverse Polarity Protection
· Ultra High-Speed Switching
· Freewheeling
· Polarity Protection Diode
· Recirculating Diode
· Switching Diode
Product Description
| Type | Description |
| ANSC PART# | ANSC- MUR420 |
| Category | Discrete Semiconductor Products |
| Diodes | |
| Rectifiers | |
| Single Diodes | |
| Mfr | Original |
| Series | SWITCHMODE™ |
| Packaging | Bulk |
| Part Status | Obsolete |
| Technology | Standard |
| Voltage - DC Reverse (Vr) (Max) | 200 V |
| Current - Average Rectified (Io) | 4A |
| Voltage - Forward (Vf) (Max) @ If | 890 mV @ 4 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 35 ns |
| Current - Reverse Leakage @ Vr | 5 µA @ 200 V |
| Capacitance @ Vr, F | - |
| Mounting Type | Through Hole |
| Package / Case | DO-201AA, DO-27, Axial |
| Supplier Device Package | Axial |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Base Product Number | MUR42 |
