Product Description
The STD35P6LLF6 is a P-Channel MOSFET transistor designed for switching applications. It features a single-channel configuration with a built-in diode and operates in enhancement mode. This transistor is part of the STripFET F6 series, known for its high performance and reliability.
Product Features
· High current handling: The STD35P6LLF6 can handle continuous drain currents of up to 35A, making it suitable for demanding applications.
· Low on-resistance: The transistor's drain-source on-resistance is as low as 0.036Ω, reducing power loss and heat generation.
· High voltage tolerance: The transistor can withstand a drain-source breakdown voltage of up to 60V, ensuring reliable operation in a variety of environments.
· Compact packaging: The transistor is packaged in a TO-252-3 (DPak) package, which is surface-mountable and has a compact footprint.
Product Applications
· Primary applications:
· Switching power supplies
· Motor control circuits
· Power conversion systems
· Secondary applications:
· Audio amplifiers
· LED drivers
· Power management systems
Product Description
| Type | Description |
| ANSC PART# | ANSC- STD35P6LLF6 |
| Category | Discrete Semiconductor Products |
| Transistors | |
| FETs, MOSFETs | |
| Single FETs, MOSFETs | |
| Mfr | - |
| Series | STripFET™ F6 |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Part Status | Active |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 35A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 28mOhm @ 17.5A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 30 nC @ 4.5 V |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 3780 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 70W (Tc) |
| Operating Temperature | -55°C ~ 155°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | DPAK |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Base Product Number | STD35 |
