Product Details
FEATURES
● Switching and Linear Amplification
● High Current and Low Voltage
● Complement to PXT2222A
Product Description
| PART# | PXT2907A |
| Rohs Code | Yes |
| Part Life Cycle Code | Transferred |
| Reach Compliance Code | Unknown |
| Collector Current-Max (IC) | 0.6 A |
| Configuration | Single |
| DC Current Gain-Min (hFE) | 50 |
| JESD-609 Code | e3 |
| Number of Elements | 1 |
| Operating Temperature-Max | 150 °C |
| Peak Reflow Temperature (Cel) | 260 |
| Polarity/Channel Type | Pnp |
| Power Dissipation-Max (Abs) | 1 W |
| Surface Mount | Yes |
| Terminal Finish | Matte Tin |
| Transition Frequency-Nom (fT) | 200 Mhz |
Actual image of the product
