Product Description: SRE6603-103M Fixed Inductor Description The SRE6603-103M is a high-performance, wirewound fixed inductor designed for a wide range of power applications. This surface-mount device (SMD) features a ferrite core and is optimized for use in power inductor applications where high current handling and low DC resistance are critical. With its compact rectangular package and dual-ended wraparound terminals, it offers excellent thermal performance and reliability. Features High Current Handling: The inductor can handle a maximum DC current of 20mA, making it suitable for demanding power supply designs. Low DC Resistance: The DCR (DC Resistance) is maximally 32.8 Ohms, ensuring efficient energy transfer in power circuits. High Inductance: With an inductance value of 10mH, this inductor provides significant filtering capabilities in power supply designs. Frequency-Self-Resonant: The self-resonant frequency is 800kHz, allowing for stable operation across a broad frequency range. Operating Temperature Range: The inductor operates reliably within the temperature range of -25°C to 105°C. RoHS3 Compliant: Meets all requirements for RoHS3 compliance, ensuring environmental sustainability. Shielding: The inductor is shielded to minimize electromagnetic interference (EMI). Applications Primary Applications: Power Supply Filtering: The high inductance and low DCR make it ideal for filtering in power supplies. DC-DC Converters: Suitable for use in DC-DC converters where high current handling is required. Motor Control Circuits: The inductor's high Q factor at 100kHz ensures stable operation in motor control circuits. Secondary Applications: Audio Filtering: Can be used in audio circuits for filtering out unwanted frequencies. Medical Devices: Due to its reliability and stability over a wide temperature range, it can be used in medical devices requiring precise filtering. |
Product Description
| Type | Description |
| ANSC PART# | ANSC-SRE6603-103M |
| Category | Inductors, Coils, Chokes |
| Fixed Inductors | |
| Mfr | Original |
| Series | SRE6603 |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| / | |
| Part Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 10 mH |
| Tolerance | ±20% |
| Current Rating (Amps) | 20 mA |
| Current - Saturation (Isat) | 17mA |
| Shielding | Shielded |
| DC Resistance (DCR) | 32.8Ohm Max |
| Q @ Freq | 50 @ 100kHz |
| Frequency - Self Resonant | 800kHz |
| Ratings | - |
| Operating Temperature |
-25°C ~ 105°C |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.260" L x 0.175" W (6.60mm x 4.45mm) |
| Height - Seated (Max) | 0.115" (2.92mm) |
| Base Product Number | SRE6603 |
